These compact ice cube machines are ideal for small-volume ice production, for limited-use needs, or as back-ups for larger machines. Specifically designed to fit beneath counters or in areas where floor space or height restrictions prohibit use of larger equipment. The petite size makes any of these models ideal for on-the-spot installations at coffee shops, stadium boxes, refreshment break areas, or wherever limited ice needs require equipment with a small footprint.
SPECIFICATIONS
MODEL CODE: QD-0132A
"A"or "W"following model number indicates "Air"or "Water"condensing unit.
DESCRIPTION: Ice Machine
EXTERIOR DIMENSIONS (WxDxH): 26" x 26.50" x 38.50"on 6" legs (66.04cm x 67.31cm x 82.55cm on 15.24cm legs)
FRONT:
ON - Initiate Ice
OFF - Stop
CLEAN - Initiates cleaning
BACK:
Electrical Entrance
3/8" (0,95 cm) F.P.T. Ice Making Water Inlet
1/2" (1,27 cm) Minimum F.P.T. Water Condenser Outlet (water-cooled units)
3/8 " (0,95 cm) F.P.T. Water Condenser Inlet
3/4" (1,91 cm) Bin Drain
CUBE SIZE: Dice - 7/8" x 7/8" x 7/8" (2.22 x 2.22 x 2.22 cm)
DAILY ICE PRODUCTION: 130 lbs./59 Kg
POWER kWh/100 lbs: 16.0
WATER USAGE:
Potable Water: 38.4 gallons, 146 Liters
100 LBS./45.4 Kgs. of Ice
Water-cooled Condenser: 187 gallons, 708 Liters
ELECTRICAL:
115/60/1. (208-230/60/1 also available.) For 230/50/1 see 50 cycle literature. 115/60/1 ice machines are factory pre-wired with a 6'(180 cm) power cord and NEMA 5-15P-plug configuration.
208-230/60/1 ice machines are factory pre-wired with a 6' (180 cm) power cord only, no plug is supplied.
Total Amps:
115/1/60 - 7.6 amps
208-230/60/1 - 3.3 amps
Maximum Fuse Size: Air and Water-cooled 15 amps.
HACR-type circuit breakers can be used in place of fuses.
BTU PER HOUR: 2,100 (average) 3,300 (peak)
COMPRESSOR: Nominal rating: 1 / 3 HP
OPERATING LIMITS:
Ambient Temperature Range:
35°-110°F (1.7°-43.3°C)
Water Temperature Range:
33°-90°F (0.6°-32.2°C)
Water Pressure Ice Maker Water In:
Min 20 psi (137.9 kPA)
Max 80 psi (551.1 kPA)
INSTALLATION: Recommended clearance for top, sides, and back is 5" (12.7 cm) however, there is no minimum clearance required.
AIR FILTER: Slides out from left side front without tools, easy to clean, reusable filter protects condenser from lint, grease and dust.
CLEANING SYSTEM: Built-in patented cleaning and sanitizing technology.
LEGS: 6" (15.24 cm)
LISTINGS: NSF, UL, ARI
